QSYS
NC-20x60
Q-SYS NC-20x60 is a 4K network PTZ camera for large rooms and lecture spaces where subjects sit far from the lens. A 20x optical zoom and a 60° horizontal field of view reach distant faces clearly, with PTZ mechanical presets and 3D digital noise reduction for clean images.
It is a native Q-SYS device, so routing and control run through Q-SYS OS and Q-SYS Designer Software over a single Gigabit Ethernet / Q-LAN connection that carries video, source and control. HDMI output runs to 2160p30 and 3G-SDI to 1080p60, while USB bridging via a Q-SYS peripheral feeds a soft codec at up to 1080p30. PoE Type 1 Class 3 or 12V DC keeps cabling simple.
Within an AVSTEK design, NC-20x60 sits on a unified Q-SYS ecosystem aligned to AVIXA viewing guidance for coherent, scalable rooms.
Q-SYS NC-20x60 is a 4K network PTZ camera for large rooms and lecture spaces where subjects sit far from the lens. A 20x optical zoom and a 60° horizontal field of view reach distant faces clearly, with PTZ mechanical presets and 3D digital noise reduction for clean images.
It is a native Q-SYS device, so routing and control run through Q-SYS OS and Q-SYS Designer Software over a single Gigabit Ethernet / Q-LAN connection that carries video, source and control. HDMI output runs to 2160p30 and 3G-SDI to 1080p60, while USB bridging via a Q-SYS peripheral feeds a soft codec at up to 1080p30. PoE Type 1 Class 3 or 12V DC keeps cabling simple.
Within an AVSTEK design, NC-20x60 sits on a unified Q-SYS ecosystem aligned to AVIXA viewing guidance for coherent, scalable rooms.
20x optical zoom, 60° horizontal field of view suitable for large spaces where clear image detail is needed.
Video distribution over Q-LAN, easy to scale and route within the AV&C system.
Power over Ethernet (PoE), simple installation with a single cable.
Comprehensive image control: white balance, focus, exposure.
Configurable resolution & IP stream quality (up to 1080p).
Image rotation control → supports ceiling mounting with the PTZ-CMB1 accessory.
Local 12V power supply (power supply not included).
PTZ-WMB1 wall mount accessory included for easy installation.
Comprehensive management via Q-SYS Designer Software and Q-SYS Reflect Enterprise Manager.
